High Filtration Efficiency Pleated Air Filters F9 12x24x12 For Cleanroom
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | SGAIR |
| Certification: | CE / ISO9001 |
| Model Number: | Pleated Air Filters |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Negotiable |
| Delivery Time: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 1000 PCS Per Week |
|
Detail Information |
|||
| Material: | Wet-laid Fine Fiber | Keyword: | Pleated Air Filters |
|---|---|---|---|
| Application: | Clean Room / Hotel / Industry | Size: | Customized |
| Logo: | SGAIR / OEM | Efficiency: | F9 |
| Condition: | New | Feature: | High Durability |
| Highlight: | Cleanroom Pleated Air Filters,F9 Efficiency Pleated Air Filters,12x24x12 Pleated Air Filters |
||
Product Description
High Filtration Efficiency Pleated Air Filters Easy To Clean And Reuse
Nominal size | Actual size | Partition | Flange | Rated air volume |
(inch) | (mm) | (V) | (non/single) | (m3/h) |
W×H×D | W×H×D | |||
12×24×12 | 287×592×292 | 2V | Single flange | 1200 |
24×12×12 | 592×287×292 | 4V | Single flange | 1200 |
24×20×12 | 592×492×292 | 4V | Single flange | 2200 |
24×24×12 | 592×592×292 | 4V | Single flange | 2700 |
12×24×12 | 305×610×292 | 2V | Non-flange | 1400 |
24×24×12 | 610×610×292 | 4V | Non-flange | 3000 |
Nominal size | Surface air speed | Rated initial resistance | Recommended final resistance | |||
(inch) | (m/s) | (Pa) | (Pa) | |||
W×H×D | F6 | F7 | F8 | F9 | Double initial resistance | |
12×24×12 | 2.50 | 110 | 120 | 130 | 140 | Double initial resistance |
24×12×12 | 2.50 | 110 | 120 | 130 | 140 | Double initial resistance |
24×20×12 | 2.50 | 110 | 120 |
130 | 140 | Double initial resistance |
24×24×12 | 2.50 | 110 | 120 | 130 | 140 | Double initial resistance |
12×24×12 | 2.50 | 110 | 120 | 130 | 140 | Double initial resistance |
24×24×12 | 2.50 | 110 | 120 | 130 | 140 | Double initial resistance |
Advantage
1. Large filtration area
2. Unique structure and open bag
3. High dust capacity
4. Long life
5. Low energy consumption
6. Anti-corrosion
7. Simple recycling
Application
1. Home environment
Home is the main place for our daily life. HEPA filters can effectively remove dust, pollen, pet hair, etc. in the home, improve indoor air quality, and are very helpful to residents' health.
2. Medical places
Hospitals, clinics and other medical places have high requirements for air cleanliness. HEPA filters can filter harmful substances such as bacteria and viruses to ensure the health and safety of patients and medical staff.
3. Clean workshops
For clean workshops in the pharmaceutical, semiconductor, aerospace and other industries, HEPA filters can effectively remove various tiny particles and maintain an ultra-clean air environment.
There are 45%, 65%, 85%, 95%, 98% five kinds of efficiency of the bag filter can choose
Features:
1. Large surface area: Pleated filter media has a large specific surface area and can effectively capture more particles.
2. Low pressure loss: Compared with flat filters, the pleated structure can maintain lower pressure loss at higher flow rates.
Specifications:
| Size(WxHxD)mm | Filter Efficiency | Media area m3 | Airflow/pressure drop m3/h/Pa |
| 305x610x292 | E10 | 14 | 2000/160 |
| 595x595x292 | E10 | 21 | 4000/160 |
| 610x610x292 | E10 | 35 | 5000/160 |
| 305x610x292 | E12 | 16 | 1500/110 |
| 595x595x292 | E12 | 33 | 3400/110 |
| 610x610x292 | E12 | 40 | 4000/110 |
| 289x595x292 | H13 | 16 | 1300/110 |
| 595x595x292 | H13 | 38 | 3200/110 |
| 610x610x292 | H13 | 40 | 4000/110 |
